Specifications:

• Switch Type: Layer 2


• Type of Port Required: Gigabit Copper


• Number of Ports: 5 - 16


• PoE Type Required: None


• High Speed Stacking: No


• Design: Desktop | Fanless


• 1000Base-T ports: 5 Ports


• Switching Capacity: 10 Gbps


• QoS: Yes


• Spanning Tree Protocol: Yes


• Link Aggregation: Yes


• VLAN: 32 Groups


• Surveillance VLAN: Yes


• Jumbo Frame: 9216 bytes


• Voice VLAN: Yes


• IGMP Snooping: Yes


• Cable Diagnostics: Yes


• Energy Saving Technology: EEE Compliant | D-Link Green | RoHS 6 Compliant


• 19 Inch Rack Mountable: No


• Fans: Fanless


• Dimensions (Size): 100 x 82 x 28 mm


• Web-based GUI: Yes


• Command Line Interface: No


• Types of ports: Gigabit Ports


• Static Routing: No


• Switch Series: DGS-1100 Series

Features:

• 5 x 10/100/1000BASE-T ports


• Fanless design for silent operation


• Bandwidth Control ensures latency-sensitive traffic always gets the bandwidth it needs


• Quality of Service further prioritizes latency-sensitive traffic, ensuring timely delivery


• Segregate different types of traffic, such as surveillance or voice, with VLANs to heighten security


• IGMP Snooping sends multicast traffic only where it needs to go, significantly cutting down network traffic


• Innovative energy saving features are good for your budget, as well as the environment


• Get up and going quickly with streamlined first-time setup and ongoing management
