Specifications:

• Form Factor: Tower


• UPS Topology: Line-interactive


• Energy Saving Technology: GreenPower UPS Bypass Technology


• Active PFC Compatibility: Yes


• Nominal Input Voltage ( Vac ): 220, 230, 240


• Input Voltage Range ( Vac ): 169 - 271


• Input Frequency ( Hz ): 50 � 3, 60 � 3


• Input Frequency Detection: Auto-sensing


• Rated Input Current ( A ): 10


• Input Connector Type: IEC C14


• Detachable Power Cord Plug Type: Schuko x


• Power Cord Length (m.): 1.83


• Capacity (VA): 1600


• Capacity (Watts): 1000


• On Battery Waveform: Pure Sine Wave


• On Battery Voltage(s) ( Vac ): 230 � 5 % (Under a test load of less than 60%. When the load is greater than 60%, the output voltage range may be greater than 5%.)


• On Battery Frequency ( Hz ): 50 � 1%, 60 � 1%


• Automatic Voltage Regulation (AVR): Single Boost


• Overload Protection: Internal Current Limiting


• Outlet(s): 6


• Outlet Type: Schuko x 6


• Outlet(s) - Battery & Surge Protected: 6


• Typical Transfer Time ( ms ): 8 (Max 12ms at normal sensitivity)


• USB Charging Port(s): USB-A x 1, USB-C x 1


• USB Charging Total Output ( Watts ): 30


• USB-A Charging Output: 5 V/ 2.4 A Max


• USB-C Charging Output: 5 V/ 2.5 A Max, 9 V/ 2 A Max, 15 V/ 2 A Max


• Runtime at Half Load ( min ): 9.7


• Runtime at Full Load ( min ): 2.6


• Typical Recharge Time ( Hours ): 8 (Recover to 90% after full load discharge)


• User-replaceable: Yes


• Battery Type: Sealed Lead-acid


• Replacement Battery Pack (RBP): RBP0142


• Replacement Battery Pack (RBP) Quantity ( pcs ): 1


• Surge Suppression ( Joules ): 405


• Network Protection RJ45: 1-in, 1-out


• LCD Panel: Yes


• LCD Types: Color LCD


• Tiltable LCD Panel: 22


• LCD Information Display: Operation Type, Power Status, Battery Status, Load Status, Fault & Warning, Event & Log


• LCD Setting & Control: Alarm Setting, Input & Output, Battery Setting, Event & Log


• LED Indicators: Power On


• HID-Compliant USB Port(s): 1


• Serial Port: Dry Contact


• Audible Alarms: Battery Mode, Low Battery, Overload, UPS Fault


• Management Cable ( pcs ): USB Cable x1


• Ethernet Data Transmission Speed: Up to 1Gbps


• Power Management Software: PowerPanel Business (Recommended)


• SNMP/HTTP Remote Monitoring: Yes - with optional RMCARD205


• Dimensions: 100 x 280 x 355mm


• Weight: 11kg


• Operating Temperature: 0 - 40C


• Operating Relative Humidity (Non-condensing) ( % ): 0 - 95


• Operating Elevation: 0-3,000m


• Storage Temperature: -15 - 45


• Storage Relative Humidity (Non-condensing) ( % ): 0 - 95


• Storage Elevation: 0-15,000m


• Online Thermal Dissipation ( BTU/hr ): 24


• Certifications: CE, RoHS


• Warranty: 2-year

Features:

• Line-interactive UPS Topology


• Active PFC Compatible


• Automatic Voltage Regulation (AVR)


• LED Status Indicator


• PowerPanel Management Software


• USB Charging Port(s)


• Tower Form Factor


• Energy Saving Technology


• Pure Sine Wave Output


• Color LCD Panel


• SNMP/HTTP Remote Management Capability (Optional)


• Surge and Spike Protection


• High-speed Ethernet Data Transmission
