Specifications:

• Phase: Single Phase


• Form Factor: Rackmount Tower


• UPS Topology: Online Double Conversion


• Energy Saving Technology: Online ECO Mode Efficiency > 96%


• Active PFC Compatibility: Yes


• Parallel Expansion (Max. Units): 4


• Generator Compatibility: Yes


• Nominal Input Voltage ( Vac ): 230


• Input Voltage Range ( Vac ): 110 - 276


• Adjustable Voltage Range ( Vac ): 0-80% Load for 110 - 276 Vac | 0-100% Load for 176 - 276 Vac


• Input Frequency ( Hz ): 50 � 5 | 60 � 6


• Input Frequency Detection: Auto-sensing


• Rated Input Current ( A ): 27.3


• Input Power Factor: 0.99


• Input Connector Type: Hardwire Terminal Block


• Output Capacity (VA): 6000


• Output Capacity (Watts): 5400


• On Battery Waveform: Pure Sine Wave


• On Battery Voltage(s) ( Vac ): 208 � 1% | 220 � 1% | 230 � 1% | 240 � 1%


• Output Voltage Setting: Configurable


• On Battery Frequency ( Hz ): 50 � 0.1% | 60 � 0.1%


• Output Frequency Setting: Configurable


• Power Factor: 0.9


• ECO Mode Voltage Tolerance: � 10 %


• Overload Protection: Internal Current Limiting, Circuit Breaker, Fuse


• Overload Protection (Line Mode): 105-125% Load for 10 min, 125-150% Load for 1 min, 150-170% Load for 10 sec, >170% Load for 1 sec


• Overload Protection (Battery Mode): 105-125% Load for 2 min, 125-150% Load for 30 sec, >150% Load for 1 sec


• Overload Protection (Bypass Mode): 125-150% Load for 1 min, 150-170% Load for 10 sec, >170% Load for 1 sec


• Crest Factor: 3 : 1


• Harmonic Distortion (Linear Load): THD?2%


• Harmonic Distortion (Non-linear Load): THD?5%


• Internal Bypass: Automatic Bypass, Manual Bypass


• Typical Recharge Time ( Hours ): 7


• Maximum Charging Current ( A ): 4


• Start On Battery: Yes


• Smart Battery Management (SBM): Yes


• User-replaceable: No


• Battery Type: Sealed Lead-acid


• Compatible Extended Battery Module (EBM): BPSE240V75ART3U


• Max. EBM Quantity ( pcs ): 15


• Surge Suppression ( Joules ): 445


• EMI/RFI Filtration: Yes


• LCD Information Display: Operation Type, Power Status, Battery Status, Load Status, Fault & Warning, Other Information, Event & Log


• LCD Setting & Control: Mode Setting, Alarm Setting, Input & Output, Battery Setting, Fault & Warning, Communication, Event & Log, Security Setting


• LED Indicators: Line Mode, Battery Mode, Bypass Mode, UPS Fault


• HID Compliant USB Port(s): 1


• Dry Contact (with Relay): Optional


• Emergency Power Off (EPO) Port: Yes


• Audible Alarms: Battery Mode, Low Battery, Overload, Overcharge, Overheat, UPS Fault


• Power Management Software: PowerPanel Business (Recommended)


• SNMP/HTTP Remote Monitoring: Yes - with optional RMCARD205


• Enclosure Construction: Metal


• Rackmount Rail: Yes


• Rackmount Ears: Yes


• Certification: CE


• RoHS: Yes


• Product Warranty: 2 Years

Features:

• Online (Double Conversion) UPS Topology


• UPS Parallel Expansion


• Overload Protection


• Smart Battery Management (SBM)


• Surge and Spike Protection


• LCD Status Display


• PowerPanel Management Software


• Rack/Tower Convertible Configurations


• ECO Mode


• Generator Compatible


• Zero Transfer Time


• Extended Battery Module (EBM)


• EMI and RFI Filtration


• Emergency Power Off (EPO) Port


• SNMP/HTTP Remote Management Capability
