Specifications:

• Phase: Single Phase


• Form Factor: Tower


• UPS Topology: Line-interactive


• Energy Saving Technology: GreenPower UPS Bypass Technology


• Generator Compatibility: Yes


• Nominal Input Voltage ( Vac ): 230 � 10%


• Input Voltage Range ( Vac ): 167 ~ 295


• Input Frequency ( Hz ): 50 � 5 | 60 � 5


• Rated Input Current ( A ): 4.35


• Input Connector Type: IEC C14


• Power Cord Length (m.): 1.5


• Output Capacity (Watts): 550


• On Battery Waveform: Simulated Sine Wave


• On Battery Voltage(s) ( Vac ): 230 � 10%


• On Battery Frequency ( Hz ): 50 � 1% | 60 � 1%


• Automatic Voltage Regulation (AVR): Single Boost, Single Buck


• Overload Protection: Circuit Breaker


• Outlet(s) - Total: 3


• Outlet(s) - Battery & Surge Protected: 3


• Typical Transfer Time ( ms ): 4


• Runtime at Half Load ( min ): 9


• Runtime at Full Load ( min ): 1


• Typical Recharge Time ( Hours ): 8


• Start On Battery: Yes


• User-replaceable: No


• Battery Type: Sealed Lead-acid


• Surge Suppression ( Joules ): 450


• EMI/RFI Filtration: Yes


• Phone/Network Protection RJ11/RJ45 (Combo): 1-in, 1-out


• LCD Information Display: Operation Type, Power Status, Battery Status, Load Status, Fault & Warning, Other Information


• LCD Setting & Control: Mode Setting, Alarm Setting, Input & Output, Battery Setting, Fault & Warning


• HID Compliant USB Port(s): 1


• Audible Alarms: Battery Mode, Low Battery, Overload, UPS Fault


• Management Cable ( pcs ): USB Cable x1


• Ethernet Data Transmission Speed: Up to 1Gbps


• Power Management Software: PowerPanel Personal (Recommended)


• Enclosure Construction: Plastic


• Dimensions: 100 x 227 x 260mm


• Weight: 6.23kg


• Certifications: CE, RCM

Features:

• Line-interactive UPS Topology


• Generator Compatible


• Automatic Voltage Regulation (AVR)


• High-speed Ethernet Data Transmission


• Surge and Spike Protection


• PowerPanel Management Software


• Energy Saving Technology


• Simulated Sine Wave Output


• LCD Status Display


• USB Connectivity Port


• Serial Connectivity Port
