Specifications:

• Phase: Single Phase


• Form Factor: Rackmount


• UPS Topology: Line-interactive


• Energy Saving Technology: GreenPower UPS Bypass Technology


• Nominal Input Voltage ( Vac ): 230


• Input Voltage Range ( Vac ): 165 - 271


• Input Frequency ( Hz ): 50 � 3 | 60 � 3


• Input Frequency Detection: Auto-sensing


• Rated Input Current ( A ): 10


• Input Connector Type: IEC C14


• Detachable Power Cord Plug Type: IEC C14 x 1


• Power Cord Length (m.): 1.83


• Output Capacity (Watts): 360


• On Battery Waveform: Simulated Sine Wave


• On Battery Voltage(s) ( Vac ): 230 � 10%


• On Battery Frequency ( Hz ): 50 � 1% | 60 � 1%


• Power Factor: 0.6


• Automatic Voltage Regulation (AVR): Single Boost


• Overload Protection: Internal Current Limiting, Circuit Breaker


• Outlet(s) - Total: 6


• Outlet Type: IEC C13 x 6


• Outlet(s) - Battery & Surge Protected: 4


• Outlet(s) - Surge-Only Protected: 2


• Typical Transfer Time ( ms ): 4


• Runtime at Half Load ( min ): 13


• Runtime at Full Load ( min ): 4


• Typical Recharge Time ( Hours ): 8


• Start On Battery: Yes


• User-replaceable: Yes


• Hot-swappable: Yes


• Battery Type: Sealed Lead-acid


• Replacement Battery Pack: RBP0019


• RBP Quantity ( pcs ): 1


• Surge Suppression ( Joules ): 405


• EMI/RFI Filtration: Yes


• Phone/Network Protection RJ11/RJ45 (Combo): 1-in, 1-out


• LCD Information Display: Operation Type, Power Status, Battery Status, Load Status, Other Information


• LCD Setting & Control: Mode Setting, Alarm Setting, Input & Output


• HID Compliant USB Port(s): 1


• Serial Port: Dry Contact


• Audible Alarms: Battery Mode, Low Battery, Overload, UPS Fault


• Management Cable ( pcs ): Power Cord x4, USB Cable x1


• Power Management Software: PowerPanel Business (Recommended)


• SNMP/HTTP Remote Monitoring: Yes - with optional RMCARD205


• Enclosure Construction: Metal


• Rackmount Ears: Yes


• Dimensions: 433 x 44 x 235mm


• Weight: 7.8kg


• Certifications: CE, EAC, RCM

Features:

• Line-interactive UPS Topology


• Simulated Sine Wave Output


• Overload Protection


• Surge and Spike Protection


• Phone/Fax/Modem/DSL/Network Protection


• USB Connectivity Port


• SNMP/HTTP Remote Management Capability (Optional)


• Energy Saving Technology


• Automatic Voltage Regulation (AVR)


• Hot-swappable Batteries


• EMI and RFI Filtration


• LCD Status Display


• PowerPanel Management Software
