Specifications:

• Phase: Single Phase


• Form Factor: Rackmount, Tower


• UPS Topology: Line-interactive


• Energy Saving Technology: GreenPower UPS Bypass Technology


• Energy Star Qualified: Yes


• Active PFC Compatibility: Yes


• Nominal Input Voltage ( Vac ): 220 | 230 | 240


• Input Voltage Range ( Vac ): 159 ~ 288


• Adjustable Voltage Range ( Vac ): 151 ~ 302 Vac


• Input Frequency ( Hz ): 50 � 3 | 60 � 3


• Input Frequency Detection: Auto-sensing


• Rated Input Current ( A ): 16


• Input Connector Type: IEC C20


• Power Cord Length (m.): 3


• Output Capacity (Watts): 3000


• On Battery Waveform: Pure Sine Wave


• On Battery Voltage(s) ( Vac ): 220 � 5% | 230 � 5% | 240 � 5%


• On Battery Frequency ( Hz ): 50 � 1% | 60 � 1%


• Power Factor: 1


• Automatic Voltage Regulation (AVR): Double Boost, Single Buck


• Overload Protection: Internal Current Limiting, Circuit Breaker


• Outlet(s) - Total: 8


• Outlet Type: IEC C13 x 6 | IEC C19 x 2


• Outlet(s) - Battery & Surge Protected: 8


• Outlet(s) - Critical Load (CL): 4


• Outlet(s) - Non-Critical Load (NCL): 4


• Typical Transfer Time ( ms ): 4


• Runtime at Half Load ( min ): 7.1


• Runtime at Full Load ( min ): 1.7


• Typical Recharge Time ( Hours ): 3


• Start On Battery: Yes


• Built-in Battery Management Module: Yes


• User-replaceable: Yes


• Hot-swappable: Yes


• Battery Type: Sealed Lead-acid


• Battery Cartridge: RBP0129


• RBP Quantity ( pcs ): 1


• Battery Quantity (Each RBP) ( pcs ): 4


• Compatible Extended Battery Module (EBM): BP48VP2U02 (Built-in Charger)


• Max. EBM Quantity ( pcs ): Unlimited


• Surge Suppression ( Joules ): 2430


• EMI/RFI Filtration: Yes


• Network Protection RJ45: 1-in, 1-out


• LCD Orientation: Rotatable LCD � Manual


• LCD Information Display: Operation Type, Power Status, Battery Status, Load Status, Fault & Warning, Other Information, Event & Log


• LCD Setting & Control: Mode Setting, Alarm Setting, Input & Output, Battery Setting, Communication, Language


• HID Compliant USB Port(s): 1


• Dry Contact (with Relay): Yes


• Emergency Power Off (EPO) Port: Yes


• Audible Alarms: Battery Mode, Low Battery, Overload, Overcharge, Overheat


• Management Cable ( pcs ): Power Cord x4, USB Cable x1, Serial Cable x1, EPO Cable x1


• Ethernet Data Transmission Speed: Up to 1Gbps


• Power Management Software: PowerPanel Business (Recommended)


• SNMP/HTTP Remote Monitoring: Yes - with optional RMCARD205


• PowerPanel Cloud Service: Yes - 90 Days Free Trial


• Enclosure Construction: Metal


• Rackmount Rail: Yes


• Rackmount Ears: Yes


• Dimensions: 433 x 86.5 x 500mm


• Weight: 32.8kg


• Certifications: CE, FCC Class A, UL, cUL, RCM, VCCI, UKCA

Features:

• Line-interactive UPS Topology


• Active PFC Compatible


• Toolless Battery Replacement


• High Output Power Factor


• Overload Protection


• Quick Charging Technology


• Extended Battery Module (EBM)


• EMI and RFI Filtration


• USB Connectivity Port


• Emergency Power Off (EPO) Port


• SNMP/HTTP Remote Management Capability (Optional)


• Energy Saving Technology


• Pure Sine Wave Output


• Battery Management Technology


• Automatic Voltage Regulation (AVR)


• Critical/Non-critical Load Outlets


• Hot-swappable Batteries


• Surge and Spike Protection


• LCD Status Display


• Serial Connectivity Port


• PowerPanel Management Software


• Rack/Tower Convertible Configurations
