Specifications:

• Phase: Single Phase


• Form Factor: Desktop


• UPS Topology: Line-interactive


• Energy Saving Technology: GreenPower UPS Bypass Technology


• Nominal Input Voltage ( Vac ): 230 � 10%


• Input Voltage Range ( Vac ): 170 - 290


• Input Frequency ( Hz ): 50 � 5 | 60 � 5


• Input Frequency Detection: Auto-sensing


• Rated Input Current ( A ): 4.55


• Power Cord Length (m.): 1.5


• Output Capacity (Watts): 600


• On Battery Waveform: Simulated Sine Wave


• On Battery Voltage(s) ( Vac ): 230 � 10%


• On Battery Frequency ( Hz ): 50 � 1% | 60 � 1%


• Automatic Voltage Regulation (AVR): Single Boost, Single Buck


• Overload Protection: Circuit Breaker


• Outlet(s) - Total: 8


• Outlet(s) - Battery & Surge Protected: 4


• Outlet(s) - Surge-Only Protected: 4


• Typical Transfer Time ( ms ): 4


• USB Charging Port(s): USB-A x 1


• USB Charging Current: 5 V/ 1 A


• Runtime at Half Load ( min ): 6


• Runtime at Full Load ( min ): 1


• Runtime at 60W ( min ): 60


• Runtime at 90W ( min ): 42


• Typical Recharge Time ( Hours ): 8


• Battery Type: Sealed Lead-acid


• Battery Cartridge: RBP0117


• RBP Quantity ( pcs ): 1


• Surge Suppression ( Joules ): 150


• EMI/RFI Filtration: Yes


• Phone/Network Protection RJ11/RJ45 (Combo): 1-in, 1-out


• LCD Panel: Yes


• LCD Information Display: Power Status, Battery Status, Load Status, Other Information


• HID Compliant USB Port(s): 1


• Audible Alarms: Battery Mode, Low Battery, Overload, UPS Fault


• Management Cable ( pcs ): USB Cable x 1, Phone Line x 1


• Power Management Software: PowerPanel Personal (Recommended)


• Enclosure Construction: Plastic


• Dimensions: 166 x 118 x 288mm


• Weight: 6.5kg

Features:

• Line-interactive UPS Topology


• Simulated Sine Wave Output


• USB Charging Port(s)


• Phone/Fax/Modem/DSL/Network Protection


• PowerPanel Management Software


• Energy Saving Technology


• Automatic Voltage Regulation (AVR)


• Surge and Spike Protection


• LCD Status Display


• Wall Mount Installation
