About Lindy 5m USB 3.2 Active Ext

Lindy 5m USB 3.2 Gen 1 Active Extension Type C to C

Features

•
  5 metre USB 3.2 Active Extension Repeater Cable



•
  Supports transfer rates up to 5Gbps



•
  DC socket for connection of an optional external power supply



•
  Plug & Play



•
  2 year warranty


Specifications

Connectors

•
  Connector A: USB Type C Male



•
  Connector B: USB Type C Female



•
  Power: 3.5/1.35mm DC Connector



•
  Housing Material: Aluminium



•
  Connector Plating: Nickel plated shell



•
  Pin Construction: Copper



•
  Pin Plating: Gold



•
  Dimensions (approx.) WxDxH:





•
  USB C Male: 11.65x36x6.5mm (0.46x1.42x0.26in)



•
  USB C Female (housing): 28.6x45x14.1mm (1.13x1.77x0.56in)


Cable Construction

•
  Length: 5m (16.4ft)



•
  Standard: USB 3.1 Gen 1 / 3.0



•
  Colour: Black



•
  Type: Round



•
  Jacket Diameter: 4.6mm (0.18in)



•
  Jacket Material: PVC



•
  Conductor Material: Tinned Copper



•
  Conductor Gauge: 28AWG+28AWG+22AWG



•
  Shielding: 85% TC


Specifications

•
  Supported Bandwidth: 5Gbps



•
  Minimum Bend Radius: 36mm (1.42in)



•
  Operating Temperature: 0°C to 40°C (32°F - 104°F)



•
  Storage Temperature: -10°C to 60°C (14°F - 140°F)



•
  Transmission Medium: Twisted Pair



•
  Transmission Technology: USB 3.1 Gen 1 / 3.0


Miscellaneous

•
  Packaging Type: Carton Box



•
  Packaging Dimensions: 165x165x30mm (6.5x6.5x1.18in)



•
  Net Weight: 0.198kg (0.44lb)



•
  Gross Weight: 0.253kg (0.56lb)



•
  Warranty (Years): 2



•
  Certificated: CE, FCC, RoHS & REACH


Package Contents

•
  5m USB 3.2 Active Extension Cable Type C to C
