About Lindy 4K KVM Over IP Ext (R)

Lindy 4K KVM Over IP Extender - Receiver

Features

•
  Extends HDMI 4K30, USB HID and IR over an IP network



•
  Supports point to point and point to multipoint installation up to 150m



•
  HDMI 1.4 & HDCP 1.4 compliant



•
  Requires a Gigabit Ethernet (1000BaseT) compliant network for multipoint installation



•
  2 year warranty


Specifications

•
  AV Interface: HDMI



•
  Console Interface: USB



•
  Interfaces Standard: HDMI 1.4, USB (HID)



•
  Supported Bandwidth: 10.2Gbps



•
  Maximum Distance: 150m (492.12ft) (Point to Point)



•
  Maximum Resolution: 4K@30Hz (3840x2160@30Hz)



•
  HDCP Support: HDCP 1.4



•
  Supported Audio: Audio supported over HDMI signal



•
  Separate Audio Ports: -



•
  Transmission Protocol: IP



•
  Transmission Medium: Cat.5e / 6



•
  Laser Class (only for Fibre): -



•
  Wavelength (only for Fibre): -



•
  Special Features: IR Signal (25 to 56kHz) forwarding


Connectors

•
  Transmitter KVM Interfaces: -



•
  Transmitter Extension Port: -



•
  Receiver Console Interface: HDMI (Female), 2 x USB Type A (Female), IR 3.5mm (Female)



•
  Receiver Extension Port: RJ45



•
  Bi-directional Ports: -



•
  Other Interfaces: IR 3.5mm (Female)



•
  Power: 5.5/2.1mm DC socket


Physical Properties

•
  Dimensions (approx.) WxDxH: 165x80x21mm (6.5x3.15x0.83in)



•
  Housing Material: Plastic



•
  Net Weight: 0.2kg (0.45lb)



•
  Operating Temperature: 0°C - 55°C (32°F - 131°F)



•
  Storage Temperature: -10°C - 75°C (14°F - 167°F)



•
  Humidity: 10 - 80% RH (non-condensing)



•
  Power Requirements: 5VDC 2A



•
  Colour: Black


Miscellaneous

•
  Packaging Type: Carton box



•
  Packaging Dimensions: 220x170x60mm (8.66x6.69x2.36in)



•
  Gross Weight: 0.8kg (1.76lb)



•
  Warranty (Years): 2



•
  Certification: CE, FCC, RoHS, REACH
