CyberPower SMBCB400 3-Phase Modular UPS Circuit Breaker

About CyberPower SMBCB400 3-Phase Modular UPS Circuit Breaker

CP Circuit Breaker 400A

Specifications:

•
  Product Category: Circuit Breaker



•
  Poles: 3



•
  Rated Insulation Voltage ( Vac ): 1000



•
  Rated Impulse Withstand Voltage ( Vac ): 8000



•
  Rated Operating Voltage ( Vdc ): 250



•
  Rated Ultimate Short-circuit Current ( kA ): 50



•
  Rated Service Short-circuit Current ( kA ): 50



•
  Rated Current ( A ): 400



•
  Dimensions (mm): 150 x 257 x 157



•
  Weight (kg.): 5.8



•
  Dimensions (mm): 210 x 285 x 205



•
  Weight (kg.): 6.11



•
  Operating Elevation (m.): ?2000



•
  Operating Temperature (�C): -35 ~ 70



•
  Operating Relative Humidity (Non-condensing) ( % ): 90


Features:

•
  High Breaking Capacity



•
  Overcurrent Protection



•
  Short Circuit Protection
