About CP PFC Sinewave Series 2000VA

CyberPower Systems PFC Sinewave Series 2000VA / 1200W Tower UPS - 2U -6x IEC C13 (2x Surge Protection only) 12V/9Ah*2 high rate 2 Yrs Adv. Replacement WTY Incl. internal Batteries

Features

•
  Line-interactive UPS topology



•
  Active PFC compatible



•
  Automatic Voltage Regulation (AVR)



•
  Critical & Non-critical load outlets



•
  Color LCD panel



•
  USB connectivity



•
  PowerPanel management software



•
  Surge and spike protection



•
  Network protection



•
  Energy saving technology



•
  Pure sine wave output



•
  Overload protection



•
  Hot-swappable batteries



•
  LED status indicator



•
  High-speed Ethernet data transmission



•
  SNMP/HTTP remote management (optional)



•
  EMI/RFI filtration



•
  Short-depth chassis design


Specifications

General

•
  Phase: Single Phase



•
  Form Factor: Rackmount



•
  UPS Topology: Line-interactive



•
  Energy Saving Tech: GreenPower UPS™ Bypass



•
  Active PFC Compatibility: Yes


Input

•
  Nominal Voltage: 230 Vac



•
  Voltage Range: 169 ~ 271 Vac



•
  Frequency: 50/60 Hz ± 3 (Auto-sensing)



•
  Rated Current: 10 A



•
  Connector: IEC C14



•
  Detachable Cord: IEC C14 x1



•
  Cord Length: 6 ft / 1.8 m


Output

•
  Capacity: 2000 VA / 1200 W



•
  Waveform: Pure Sine Wave



•
  Voltage: 230 Vac ± 5%



•
  Frequency: 50/60 Hz ± 1%



•
  Power Factor: 0.6



•
  AVR: Single Boost



•
  Overload Protection: Circuit Breaker & Current Limiting



•
  Total Outlets: 8 (IEC C13)



•
  Battery & Surge Protected: 8



•
  Critical Load Outlets: 4



•
  Non-critical Load Outlets: 4


Battery

•
  Runtime: 7.9 min (Half Load), 1.3 min (Full Load)



•
  Recharge Time: 8 hours (90% recovery)



•
  User-replaceable & Hot-swappable: Yes



•
  Type: Sealed Lead-acid



•
  Replacement Battery Pack: RBP0188 (x1)


Protection & Network

•
  Surge Suppression: 900 Joules



•
  EMI/RFI Filtration: Yes



•
  Network Protection: RJ45 (1-in / 1-out)


Management & Indicators

•
  LCD Panel: Color LCD (Power, Battery, Load, Fault, Warning)



•
  LED Indicators: Power On



•
  USB Port: HID Compliant (x1)



•
  Audible Alarms: Battery Mode, Low Battery, Overload, Fault



•
  Included Cables: Power Cord x1, USB Cable x1



•
  Ethernet Speed: Up to 1Gbps



•
  Software: PowerPanel Business (Recommended)



•
  Remote Monitoring: Optional RMCARD205



•
  Cloud Service: 90 Days Free Trial


Physical

•
  Enclosure: Plastic, Black, Rackmount Ears Included



•
  Dimensions: 433 x 86 x 274 mm



•
  Weight: 12.96 kg



•
  Shipping Size: 523 x 162 x 374 mm



•
  Shipping Weight: 14.26 kg


Environmental

•
  Operating Temp: 0 ~ 40 °C (32 ~ 104 °F)



•
  Humidity: 0 ~ 95% (Non-condensing)



•
  Operating Elevation: 0 ~ 3,000 m (0-9,843 ft)



•
  Storage Temp: -15 ~ 45 °C (5 ~ 113 °F)



•
  Storage Elevation: 0 ~ 15,000 m (0-49,213 ft)



•
  Heat Dissipation: 23.9 BTU/hr


Certifications

•
  CE



•
  RoHS
